Coach Focus Room

• 42" (107cm) min. clearance at the table for seating
• 36” (91.5cm) min. clearance for circulation without seating
• 60” x 60” (152.5cm x 152.5cm) clear floor space on each side of all swing doors

Walls

• Wall type 1: Gypsum wall to deck
• Wall type 2: Glazing wall
• Paint with rubber base (or equivalent)
• Acoustic wall covering
• Interior glazing to match the height and width of the door. Fully sealed. Clear color
• Provide visual warnings on all glass walls

Floors

• Carpet tile (or equivalent)
• Avoid large patterned or busy graphic fabrics as they interact with the camera and cause visual telegraphing during video teleconferencing

Ceiling

• Suspended ACT (or equivalent)
• Height not to exceed 10’ (3m)

• Standard size door
• Type: Glass panel, swing
• Standard door opening based on region, minimum width 32"(81cm)
• 0.5" (1.27cm) maximum height threshold
• Require 5 lbs or less of force to open or have push-button door openers
• Handle: Metal lever-style, without lock 
• Seals at head and jambs, no gap at the door when adjacent to loud spaces 
• Provide visual warnings at all glass doors

Furniture

Ergonomic sit-to-stand desk

• Electric, adjustable height with min. range 25”-48” (63.5cm-122cm) height, 3 phase motor is typical to achieve this range
• Finishes: Top in (A)  solid wood or (B) solid color laminate with exposed MDF core at the edge. Black or white powder coat base
• Size: 30” (76cm) width, 60” (152cm) length. May vary by Region
• Height switch with digital display, located to avoid accidental contact
• Knife-edge at front preferred. Metal trough for wire management preferred, making modesty panel unnecessary.(x4) pack preferred. (x2) or (x6) optional
• Avoid clip-on power units

Ergonomic monitor arm

• Adjustable both front-to-back and to eye-level height. The position is stable with the weight of the monitor

Ergonomic task chair

• Fast, easy, and intuitive adjustments. Integrated or manual lumbar support
• Seat height: Adjustable, 15”-22” (38cm-56cm) min. height
• Seat pan: Adjustable, 15”-19” (38cm-48cm) min. depth
• Mesh back, 5-star casters for carpet, height adjustable arms
• Avoid plastic edge below the knee
• Passive tension preferred
• Ability to change to a tall or short cylinder for people outside the adjustable range
• Finish: Gray fabric/mesh/base is preferred
• Avoid arms that move in multiple directions

• Voices can’t be heard outside of the room and vice versa. Conversations and presentations are clear and easy to understand. Background noise doesn’t interfere with technology for video conferences or audio calls
• Noise criteria (NC): 30-35 dBA
• Sound transmission class (STC): 50-55 dBA

• Refer to Nike Tech Standards

Outlets

• Power at a desk for motor, monitor, and desktop outlets. No floor boxes.
• Provide (x2) min. outlets at a desk, with easy access to plugin laptop chargers. Conceal wires below the surface.
• Provide grommets and access to power within 24" (61cm) of the edge of the table
• Two electrical outlets above desk for laptop and peripheral charging
• One electrical outlet below desk for monitor
• No hardwire Data.  Users will use Wi-Fi.

Lighting

• Lighting and other controls should be mounted between 44”-48” (110cm-122cm)
• Range: Up to 30 FC (323 LUX)
• Controls: Daylight harvesting for exterior perimeter rooms. User dimmable for interior rooms.
• Fixtures: Diffused downlight or wall wash LED. One fixture type. Plan for furniture to be reconfigured.

• See Wayfinding section
• ID sign with ‘Focus Room’
• Focus Room number above or near the top of the door

• On-wall facing Entrance, select one:
• Framed posters and accent wall paint
• Wallcovering on the full wall; use tonal color
• Information systems and art are accessible.  If visual, an audio or tactile component is incorporated (e.g. closed captioning for any digital information systems, audio headsets provided for visual media)
• Wall graphics are typically paint applications, which are easier and more affordable to maintain than wallcoverings

• Refer to Nike Tech Standards

• For Workplace Security standards, contact your local Design or PM team. EHS standards can be found in Resources
